ACR (Minimum at 100-m) — 16.3 dB at 100 MHz; 1.4 dB at 200 MHz Attenuation (Minimum at 100-m) — 22.0 dB at 100 MHz; 32.4 dB at 200 MHz; 41.0 dB at 300 MHz; 44.9 dB at 350 MHz Cable Type — 4-pair UTP, 300 V Capacitance Unbalance (Maximum) — 330 pF/100-m (pair to ground) Characteristic Impedance — 1-350 MHz: 100 +/- 15 ohms Conductor — 24 AWG, solid, bare copper Conductor Resistance (Maximum) — 93.8 ohm/20° C (68° F) maximum Delay Skew (Maximum) — 1-350 MHz: 40 nS/100-m EL-FEXT (Minimum at 100-m) — 23.8 dB at 100 MHz; 17.7 dB at 200 MHz; 14.2 dB at 300 MHz; 12.9 dB at 350 MHz NEXT (Minimum at 100-m) — 38.3 dB at 100 MHz; 33.8 dB at 200 MHz; 31.2 dB at 300 MHz; 30.1 dB at 350 MHz PS-ACR (Minimum at 100-m) — PVC: 20.8 dB at 100 MHz; 14.7 dB at 200 MHz; 11.2 dB at 300 MHz; 9.9 dB at 350 MHz PS-ELFEXT (Minimum at 100-m) — 20.8 dB at 100 MHz; 14.7 dB at 200 MHz; 11.2 dB at 300 MHz; 9.9 dB at 350 MHz PS-NEXT (Minimum at 100-m) — 36.3 dB at 100 MHz; 31.8 dB at 200 MHz; 29.2 dB at 300 MHz; 28.1 dB at 350 MHz Return Loss — 20.1 dB at 100 MHz Spark Test — 2.5 KV Velocity Of Propagation (Minimum) — 62.1% at 350 MHz
